11kV 5kN Polymer Post Insulator
Product Specifications
| Voltage | 33 kV |
|---|---|
| Material | Composite Polymer |
| Color | Grey |
| Model Name/Number | REE-PL01-24F-11 |
| Rated Voltage | 11 kV |
| Brand | Rashtriya Electrical |
| Tensile Strength | 5kN |
| Spacing | 320 mm |
| Usage/Application | Distribution Lines |
| I Deal In | New Only |
| Diameter | 105mm |
| Creep Age Distance | 320mm |
| Working Voltage | 11 kV |
| Country of Origin | Made in India |
| Cantilever Strength | 5 kN |
| Size | 252mm X 105mm |
| Applicable Specification | IEC 61109, IEC 61952 |
| Flashover Voltage Low Frequency Dry | 65 kv |
| Flashover Voltage Low Frequency Wet | 40 kv |
| Flashover Voltage Critical Impulse Positive | 80 kvp |
| Flashover Voltage Critical Impulse Negative | 80 kvp |
| Withstand Voltage Power Frequency Dry | 55 kv |
| Withstand Voltage Power Frequency Wet | 35 kv |
| Withstand Voltage Impulse Positive | 75 kvp |
| Withstand Voltage Impulse Negative | 75 kvp |
| Number of Shed | 3 |
| Net Weight Approx | 1.5 kg |
| Minimum order quantity | 50 Piece |
Product Description
Polymer Post Insulator also called Composite Polymer Post, Silicone Rubber Post Insulator Insulator or Support Insulator. As per IEC:61109 and IEC:61952 under the category of high-voltage electrical insulators.
Suitable for 11kV overhead electrical/power/energy/voltage distribution/transmission lines/systems, wherever electrical insulation and support requirement is needed and industrial and other electrical equipments like transformers.
Make: Rashtriya Electrical
We are manufacturers based in India. We are supplying all across India, Nepal, Bhutan, Bangladesh, Sri Lanka, Myanmar, Middle Eastern countries and Africa.
